Perspective and geometrical drawing : adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thos. H. (Thomas H.) · Toronto, Ont. : W. Briggs · leaf 105
EL parallel toAK; join E RMP and E LMP, and produce them backwardsto meet B.L. in Z and X. Mark off XC = 4, also ZD = 4;join D RMP and C LMP, also L R V.P. and LLV.P.;through F draw FM, and through G draw GH, parallel toEL; join M L V.P. and H R V.P. to meet at N, completingthe required cube. For… … MISCELLANEOUS EXERCISES. .101 Exercise XV.—Figures in Angular FerspecfAve.(In the following consider H = 6, L.D. = 4, scale I = 1.) 1. A square whose sides are 4, lies on ground; an angletouches P.P. 2 to right; angle 45. 2. Draw same, 3 to left and 2 within P.P.; right side makesangle of 60°. 3.…
Geometrical drawing · Perspective
