Fig. 66. … In first, let AB be the given line; erect at A a perpendicularand make it equal to AB; with centre C and distance CAdescribe arc AD; with centre B and distance BA describe GEOMETRICAL DRAWING. 107 arc to meet former arc in D; join CD and BD, completingthe square. (Fig. 66.) (b) On a given diagonal…
