ts, 5 in. by 5 in. ; principals, 5 in. by 5 in. ; straining piece, 7 in. by 5 in. ; struts, 5 in. by 2^ in.For a span of 45 feet, the tie beams to be 13in. by 6 in. ; <]ueen-posts, 6 in. by C in.; principals, 6 in. by 5 in. ; sUaining piece, 7 in. by 6 in. ; struts, 5 in. by 3 in. 2039. For… … 628 THEORY OF ARCHITECTURE. Book IF. Tor a f:p:m of 50 feet, tie Learns, 13 in. by 8 in. ; queen-posts, 8 in. Lv 8 in.; small queens, 8 in. by 4 in.; principals, 8 in. by 6 in. ; straining piece, 9 in by 6 in.: struts, 5 in. by 3 in.For a span of 55 ftct, tie beams, 14 in. by 9 in.; queen-posts, 9…
