An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 662

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 662
be given. 20S.5. When a circular-headed window is above thelevel of a plane gallery ceiling, in a church for example,the cylindrical form of the window is continued till itintersects the plane of the ceiling. To find the formof the curb or pieces of wood employed for completingthe arris, let dp… … Fig. 709. 642 THEORY OF ARCHITECTURE. Book II.
