l toone of them. Join BE,bisect A B in Cand BEin F. Make CD equalto CF and draw DGperpendicular to A B.From F, with the radiusFE or FB, describe an Fig. 7S5. F.^. 7S6. arc cutting; DGatG. Draw GH perpendicular to BE cutting BE at O. Draw the diagonalsDOK and lOL perpendicular to UOK. Draw IK…
