An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth (1888)

Gwilt, Joseph, 1784-1863, Papworth, Wyatt Angelicus Van Sandau, 1822-1894 · London Longmans, Green · leaf 713

An illustration from An encyclopaedia of architecture, historical, theoretical, & practical. New ed., rev., portions rewritten, and with additions by Wyatt Papworth, 1888, leaf 713
water closet d. The dotted line o shows the line of water pipe from the cisternc in the garden, supplying the kitchen boiler. 2223c. The cistern to supply a water closet should properly be distirct from that fordomestic purposes; and when the former is placed in a confined spot, necessitating…

Architecture · Architects

Internet Archive · University of Toronto Libraries · Public Domain Mark 1.0. Free to use for anything.
