2 ft. 6 in. on centers. The outsidewalls are covered with one-ply roofing felt, overwhich in turn is placed novelty siding. The rafters are covered with % in. sheathingboard over which is placed a two-ply roofing felt. they are lapped 4 in. The inside posts are 4 x 4 in.and the braces used are 2 x… … End Elevation of Two-Story Barracks— Scale 1/16 in. to the foot /* 6 overeach Raffei p/y Roofing
