Greene, Charles E[zra] 1842- [from old catalog], Greene, Albert Emerson. [from old catalog] · Ann Arbor, Mich., Printed for the author · leaf 199
enthe braces are not inclined up hill,but are put in horizontally. 186. Shearing Stress.—If the stresses on a pair of planes areentirely tangential to those planes, o^the unit shears must be equal. Con-sider them as acting along the faces of a small prismaticparticle A B C D, which lies at O. The… … ^^ .Fig.68. INTERNAL STRESSES. 187 This construction shows further that a shear cannot actalone as a simple stress, but must be combined with an equalunit shear on a different plane. 187. Two Equal and Like Principal Stresses.—If apair of principal stresses, § 185, are equal unit stresses of…
Mechanics, Applied · Strength of materials
