The American house-carpenter; a treatise on the art of building, and the strength of materials (1867)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 40
e chord. {Art. 158.) Exarrvple.—In an arc of a circle whose radius is Y5 feet,what is the versed sine to a chord of 120 feet ? By the tablein the Appendix it will be seen that— The square of the radius, 75, equals, , . 5625The square of half the chord, 60, equals, . 3600 The difference is, 2025 The… … 28 AMERICAN HOUSE-CAICPEI^TEE. 88.—To describe the aegment of a eirde hy intersection of lines. Let a 5, {Fig. 47,) be the cliord, and c d the height of the segment. Through c, draw e f parallel to ah ; draw h f at right angles to ch ; make c e equal to c f; draw a g and h A, at right angles to a…
Carpentry · Architecture
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
