The American house-carpenter; a treatise on the art of building, and the strength of materials (1867)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 400
btain the point, e, by drawing a linefrom J, at the usual angle. In Fig. 344, join e and i; then i eand e c will define the shadow. In Fig. 345, from o, draw o i,parallel with the shelf; join i and e; then i e and e c will be theshadow required. The projections in these several examples are bounded…
Carpentry · Architecture
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
