ig 264. 369.—Case 2.— When the cylinder is large. Fig. 264 re- 214 AMERICAN HOUSE-CARPENTER. presents a plan and a vertical section of a line passing through thecentre of the rail as before. From 6, draw h k, parallel toed; ex-tend the lines, i d and j e, until they meet k h in k and / ; from… … Fig. 265. draw c t, at right angles to e c, and equal to c f at Fig. 264 ; fromt, draw ^ 2?, parallel to c e, and make 11 equal to ^ Z at Fig. 264;complete the parallelogram, eels, and find the points, o, o, o, asbefore; then describe the circles and complete the mould as inFig. 262. The difference…
