Gould, Lucius D., b. 1814. [from old catalog] · New York, A.J. Bicknell & co. · leaf 34
join J T, which should equal C H, Fig. 3; draw anynumber of ordinates from the plan; transfer the distances, and trace themould. The bevel for the straight wood is shown at Fig. 3, and is foundby drawing D F at right angles to A B, Fig. 1; then by extending F Dto intersect the pitch line at Fig. 3;… … Plate S Exhibits the plan for a staircase, starting with winders; the circle producedleyond a quadrant; the plank sawed square to a parallel width, the wreathforming its own easing at the newel. At Fig. 3, set up from the first step to the centre of rail, the difference inthe heights of the newel…
Stair building
