Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts (1880)

D. Appleton and Company, Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 427

An illustration from Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts, 1880, leaf 427 — wheel up- 408 MILLS, GRAIN. right driving line, 144 revolutions; 7, bevel-wheel on line, 40 revolutions; 8, cross-line driving ele-vator and bolt. The scale of these figures is 2 inches to the foot. Fig. 3025 shows on the right the corn and feed stones, fed by a shoe and damsel. On the left arethe… … simply raised and cleaned by a blast of air. The grain then is conducted to the stones and goesthrough the process of grinding. The corn- and feed-stones are what are known as open stock,while the wheat-stones are close. After the corn comes from the stones it is put into bags and isready for…

Mechanical engineering -- Dictionaries

Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
