Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts (1880)

D. Appleton and Company, Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 482

An illustration from Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts, 1880, leaf 482 — and above thebearing is a smaller table carrying the mould F. G is a moulding-board attached to the bar B, andit is obvious that, by lifting the pin and releasing the table F, the latter may be revolved, and theboard G will sweep the top of the pattern to its own edge conformation. To sweep the…

Mechanical engineering -- Dictionaries

Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
