Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 375
troke may be stillsmaller. Fig. 810 is the cross-head of the Harris-Corlissengine in which the bearing surfaces of guides areadjusted by bolts passing through wedges. On locomotives it is not unusual to have theguide on one side, as in Fig. 811, where the side-bars are of Avrought-iron andthe… … Fig. 811. MACHINE DESIGN AND MECHANICAL CONSTRUCTIONS. 359 St earn-Cylinders.—Fig. 812 is a sectional plan of a common form of smallsteam-cylinder. A is the cylinder, B the piston, h the piston-rod, D the slide-valve, ^ the valve-rod, C the valve-chest, c the chest-cover, s s thesteam-ports, e the…
Mechanical drawing
