Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 419
struct one of full size. Thedimensions are obtained by measuring from the base or zero to the inclinedlines, on ordinates corresponding to the inside diameter of pipe required. When pipes are thus put together in lengths, with couplings, it is frequentlyimpossible to take out a length of pipe for… … Fig. 946. Fig. 949 is an exterior view, and Fig. 950 a section, of the common mal-leable-iron union; p and p are the halves into which the tube is screwed, andthe joint is made by a male and female coupling. The male, h, turning on aflange on the tube p^ is screwed to the other half of the…
Mechanical drawing
