Fig. 1428. Fig.1429. Fig. 1428 is a gutter of a cottage roof. Fig. 1429 is the section of a Mansard roof, showing the side elevation of adormer-window, with the gutter below its sill. The sheet-metal forming the gutter must extend well up or back beneaththe shingles or felt, or be soldered to the…
