R, piece attached to the protecting-rod, tliat strikes a lever under the breast-beam, (whenever thgshuttle fails of performing its duty,) and stops the loom. S, picker-staff for throwing the shuttle, which receives its motion from a cam on cam-shaft, communicated by a treadle and strap T. T, strap… … E-yJiiLiti _?- V, harness-treadles, operated by the cams E E. V, crank-shaft, which gives motion to the lathe or sley. X, sley or lathe, which contams the reed.Y, harnesses for separating the warps wliile the filling pusses through, which are operated by th«Carness-cam E alternately. LOOM,…
