Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 337
w^here the piston-rod is made forked, so as, pass-ing round the shaft, to rise above it to a considerable height, from which again descends the connecting-rod to the crank. Figs. 2716 to 2721 illustrate the principle. The top of the piston-rod carries a foxir-armed cross-head h h, on each end of…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
