Appleton's dictionary of machines, mechanics, engine-work, and engineering (1869)
New York, Appleton · leaf 685
Fig. 336*7 is a half-sectional plan taken on the line v—w, in Fig. 3365. Fig. 3368 is a similar half-section taken on the line x—y. Fig. 3369 is a vertical transverse section, through the centre of the mill, exhibiting the form of sectionof the framing or standards, and the internal construction of…
Mechanical engineering
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
