he drawing, 6, shows two bolts worked out according to thefollowing formula: D = diameter of bolt. W=lJ^D + % inch.T = 24D + tV incn- The thickness of the nut is somewhat more,being just equal to D. The drawing at the bottom of the page gives two views of athree-inch pipe T. Work these out,…
