Architecture and how to sketch it : illustrated by sketches of typical examples (1910)
Roberts, H. W · London : G. Rowney and Co. · leaf 56
ired by diagonals, and from the points found on thisside horizontal lines will give the corresponding pointson the opposite side. This is a sketch in Parallel Per-spective, one side—in this case the end being parallelto the picture plane—or imaginary large sheet of glassor picture plane through… … 54 ARCHITECTURE Design, and it is one of the acknowledged difficultforms to draw ; presenting as it does very varyingform in its several positions. In illustration I purposelyshow two very ugly positions of this figure : A thecommonplace almost geometrical view ; B the straightjoint running…
Drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
