The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)
Gilroy, Clinton G · New York: : George D. Baldwin · leaf 377
ld there by a slight spring (see Fig. 167.) The lower part of thisframe is attached by an axle joint to a horizontal rod S. That endof the rod S, to which the lever Q,, is connected, is bent downward,as shown in Fig. 166, for the purpose of enabling the rod to pass overthe rocker at bottom of the… … PLAIN WEAVING. 359 At the back part of the loom there is a perpendicular shaft T,supported in brackets bolted to the side frame or standard. Uponthe upper part of this shaft is fixed an endless screw or worm takinginto the teeth of a wheel on the yarn beam; by the rotation ofwhich worm the beam is…
Weaving
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
