Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 250
Fig. 135.—Valve cam device with roller mounted on carrier,is frequently used to reduce the side thrust upon the push rod. This design of the cams is so great that the gears would be worn outbefore the timing would be materially affected. Ques. WTiat would be the main objection to lost motion in… … Fig. 136.^—Roller and carrier withjoints badly worn shown in lifting po-sition. The cam and roller shown bythe dotted lines indicate the positionof these parts if there were no lostmotion. The angle between the dottedand solid cams is the angle of rotationlost due to lost motion. Fig. 137.—Roller…
Automobiles
