Augsburg, De Resco Leo, b. 1859 · Boston, New York, Educational Pub. Co · leaf 37
ox may be drawn in nine positions, viz. :Below the eye. Fig. 2.Above the eye, Fig. 3. S4 AUGSBURGS DRAWING. At the left of the eye, Fig. 4. At the right of the eye, Fig. 5. Below and at the left of the eye, Fig. 6. Above and at the left of the eye, Fig. 7. Below and at the right of the eye. Fig. 8.… … The box is drawn as follows : 1. Draw the front face, A B C D, Fig. 11. (2) Choose thecenter of vision. (3) From the points A, B, and D draw recedinglines to the center of vision. (4) Choose the point E and drawthe remaining lines. Draw first with very light lines as in Fig. 11and then finish with…
Drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
