Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 463
.The three shoes of each group rest upon a bronze sleevewhich is in halves and which surrounds the crank-pin 464 Aviation Engines and rotates relatively to it once in each crank-shaft revo-lution. The collars, which are of tough bronze, resist theinertia forces while the direct pressure of the… … , Spark Plug Cylinder No. 3- Carburetor v.G.HAGSTROM N.Y. Fig. 193.—Three-Cylinder Anzani Air-Cooled Y-Form Engine. method of construction, modified to some extent, is usedin the LeKhone rotary cylinder engine. Both cylinders and pistons of the Anzani engines areof cast iron, the cylinders being…
