Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 465
e.The three shoes of each group rest upon a bronze sleevewhich is in halves and which surrounds the crank-pin 464 Aviation Engines and rotates relatively to it once in each crank-shaft revo-lution. The collars, which are of tough bronze, resist theinertia forces while the direct pressure of the… … .Spark Plug Cylinder No. 3- Carburetor A.6. HAGS7ROM N.Y. Fig. 193.—Three-Cylinder Anzani Air-Cooled Y-Fonn Engine. method of construction, modified to some extent, is used!in the LeRhone rotary cylinder engine. Both cylinders and pistons of the Anzani engines areof cast iron, the cylinders being…
