Bench work in wood; a course of study and practice designed for the use of schools and colleges (1905)
Goss, W. F. M. (William Freeman Myrick), 1859-1928 · Boston, New York, Ginn & company · leaf 22
t.—The outline of details, which in anyview of an object are hidden, is frequentlyshown by dotted lines. Thus, in Fig. 12, thegeneral outline of the plan and elevation shows a rectangularblock; if the circle in the plan is associated with the dottedlines in the elevation, it is not difficult to… … 4 BENCH WORK IN WOOD. than at the bottom, the drawing will appear as shown by Fig. 14;if smaller at the top, as shown by Fig. 15. In Fig. 16 dotted Fig. 12 Fig. 13 Fig. 14 Fig. IS O PLAN. O PLAN. © PLAN. A— PLAN EL 1IVATlffliN, ELEVATION. eleVat/on. l 1 ELEVATION. lines indicate the diameter of a…Woodwork (Manual training)
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
