An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 336 — sameproportions, and is much the simpler method. Herein lies the dis-tinction between an isometric projection and an isometric drawing.It will be noticed that the figure may be inscribed in a circle,i hat the outline is a perfect hexagon. Hence the lines showing 180 MECHANICAL DRAWING 115 breadth…
