beam at the center. Problem 14, Fig ?8p. Howe Truss, with inclined top Chord. Forthis problem we have taken a truss like that shown by Fig. 116. Theroof loads were computed at 47 lbs. per square foot and a spacingcenter to center of trusses of 17 ft. There is no ceiling load. The STRESS PROBLEMS.… … Fig. 289,
