ah^ the part ac falls on the plane mnop and the remainder, eh, onthe plane nrso. To find the shadow of ac on the left-hand plane we must firstdetermine our ground line. The ground line will he that pro-jection of the p>lane receiving the shadoio whichis a line. In thisexample the vertical…
