economical and effective. In laying out a roof like that shown by Fig. 121, it will generallybe found most economical to divide the trusses so that the purlins(which should always be placed at or near a joint) will not be greaterthan 12 feet apart, and to space the trusses not more than 18… … Fig. 121. cp BUILDING CONSTRUCTION. 52. Roofs with Intermediate Supports.—While a truss, par-ticularly if it has a horizontal tie-beam, acts in general in the sameway as a beam, yet it differs from a beam in that it cannot, as arule, be strengthened by introducing a support between the endbearings.…
