Fig 152- verge boards are generally, although not always, supported at theirlower end by wooden brackets, which also serve to stop the gable mould-ings, or belt courses, as shown in Figs. 150 and 152, the bracketbeing used more to stop the gable finish than for an actual support. … J_J-Bj_J I Fig. 153- With an eaves finish like that shown at A, Fig. 153, with the soffit0! the eaves and raking cornice in the same plane, the verge board 172 BUILD TNG CONSTRUCTION. may be supported as shown in Section C without brackets, in whichcase the belt courses on the gable, if any, should…
