/SHINGLES LATH-^ Fig. 186. … have project on the outside of a frame wall should be built ; a 4-inchlug being carried up on each side of the chimney, as at L, and theboarding and wall covering extending over it. While this construc-tion can easily be made tight, it weakens the wall very much by cut-ting the girts and plate, and…
