Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 482
§ … BROAD STRETET FiG. 6qo.—Ground-plan of First Floor. 7,onta! thrust at the foot of the arch is taken up by a system of eye-bar ties running across the train-shed under the floor alongside of the cross-girders supporting the tracks. The illustration Fig. 6SSshows the space devoted to the market-house…
Building · Railroads
