Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 148
Fig. 484.—Conventional View of Joint betweenPrincipal Rafter and Tie-beam. The joints between principal rafter, strut,and purlin are illustrated by Fig. 486. At Fig. 487 is shown the hipped end of aqueen-post roof, and Figs. 488 and 489 showpart sectional elevation and plan of same.The upper purlin… … Fig. 487. -Conventional View showinggeneral Construction of Queen-post Roof Trusswith Hipped End. I the straining beam. The upper ends of I the queen-posts are cut to receive the purlins, as shown by the conventional view (Figs. 490 notched out part of its depth so as to fit inwith the purlins in…
Carpentry · Joinery
