Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 536
d to apply to the faceof the plank. For the moulds to apply tothe edge of the plank, proceed as follows :—The points c, d, e, /, b are projected tob c (Fig. 1645). Projecting from thesepoints parallel to a b, and drawing a lineat any convenient distance at right anglesas h k, then measuring from… … -Conventional View of Piecewith Edge Moulds Applied. Plank
Carpentry · Joinery
