The Civil engineer and architect's journal, scientific and railway gazette (1839)
London : [William Laxton] · leaf 368
A, cylinder and casing; B, the cranks; C, piston rod; D, hanginglink j E, connecting rod ; F, main frame; G, slide valve case; 11, ex-haustion pipe ; I, main beam ; K, condenser ; L, air pump ; M, hotwater cistern ; N, Iced pump ; O, O, steam pipes; P, eccentric ; Q, dis-charge pipe ; a, a, radius…
Architecture · Civil engineering · Science
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
