The complete motorist, being an account of the evolution and construction of the modern motor-car; with notes on the selection, use, and maintenance of the same; and on the pleasures of travel upon the public roads (1905)

Young, Filson, 1876-1938 · New York : McClure, Phillips & co.; London, Methuen & co. · leaf 203

An illustration from The complete motorist, being an account of the evolution and construction of the modern motor-car; with notes on the selection, use, and maintenance of the same; and on the pleasures of travel upon the public roads, 1905, leaf 203
rifices, and thus supply the engine witha rich explosive mixture for starting. As the engine speed 122 THE COMPLETE MOTORIST increases, the governor lowers the collar ; air is then admitteddirect into the main induction pipe, thus gradually reducing thestrength of the mixture until the correct… … 1—Dome to the Carburettor. 2—Jet Chamber. 3—Induction Ports. 4—Jet Chamber. 5—Air-regulating Valve. (5—Float feeder Chamber. 7—Float. 8—Guide to Float. 9—Pivoted Lever giving move-ment to Petrol Feed Valve.10—Fulcrum to which 9 is connect-11-—Petrol Supply Valve. [ed. 12—Seat for 11.13—Filter Tank…
