Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 168

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 168
stream drawn in throughthe bottom opening onthe suction stroke andissues from the opening,A, in the spray nozzle.An auxiliary air valveopens to admit more airat high engine speeds.In the form shown, asthe air valve opens itdepresses a valve in the spray nozzle and admits more fuel. The… … Drain Cock SECTION X. ELECTRIC POWER ANDDEVICES. 164 Section X. ELECTRIC POWER AND DEVICES. 392. ELECTRIC CABLE-MAKING MACHINE. A revolvingframe carrying the required number of wire bobbins. The strands aregathered by passing through a die and covered in reverse wrappings

Mechanical movements
