ecting, shafts. 2o6- MECHANISM. on the two shafts, Pi and Pa, will, at every instant, make equalangles with that plane. Moreover, in addition to the positionshown in Fig. 217, the second shaft may be parallel to the firstwithout affecting the accuracy of the motion; nor will the accuracydepend in… … ||U-D-^U Fio. 218. to connect two shafts when the direction of one or other of theaxes is subject to slight variations. It is almost invariably usedin machines designed for testing the strength of materials. Insuch machines a beam, oscillating about a fixed knife-edge, carries asecond knife-edge,…
