Dunkerley, Stanley, 1870- · London, New York [etc.] Longmans, Green · leaf 245
ed to movein a circular arc of radius P2E.The horizontal motion of the link,and therefore the departure of thepoints C and D from the verticalpaths previously assumed, will depend on the position of the centrePa; but if the position of that centre, and the length of PgE, besuch that the mean… … APPROXIMATE SOLUTIONS TO LINK MOTIONS. 235 Finally, the link CD (Fig. 254) is usually curved. In such acase, granting that the conditions just laid down are satisfied, thepoint F may be taken, not as the actual point of attachment to theblock, but as the point in which the line of stroke produced…
Machinery, Kinematics of
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
