icular to CE to meet thevertical through p in e, will therefore give the point e, and pewill be the acceleration of the piston X. Similarly, the centripetalacceleration of F about D is very small indeed, and d is obtainedby drawing df perpendicular to DF to meet the vertical in /; ACCELERATION… … ACCELERATION DIAGRAM 10 so 10 20 30 40 SO 60 70 80 90 Ft. PER SEC. PER SEC. Fio. 296. An approximate solution to the motion of the pistons X andZ may be obtained by the equivalent crank method described in§ 154, the motion of the pistons being assumed to be the same asof the points C and D. This…
