riving shaftin the manner described in § 74. The spindle F continuaUyoscillates through a certain angle and causes the reciprocatingmotion of the cutter slide. During the downstroke of the cutterslide, the blank is released from contact with the cutter bylinkwork, which it is not necessary to… … Fig. 351. mesh together, so that only one cutter is required for each pitch.This condition is satisfied for all involute teeth which have thesame obliquity (§ 176), and for all cycloidal teeth in which thefaces and flanks are generated by the same rolling circle (§ 177).An objection to cycloidal…
