Dunkerley, Stanley, 1870- · London, New York [etc.] Longmans, Green · leaf 345
Fig. 368. method in which the points of each piston are circular arcssubtending an angle of 90? at the centre—the height of the pointbeing taken as half the radius of the pitch circle. The centre ofthe circle forming the point of the piston keyed to Pg is 0, andfollowing the method of § 173, a…
Machinery, Kinematics of
