Lodge, Oliver, Sir, 1851-1940 · London, New York, Macmillan and co. · leaf 57
case when the battery is leftconnected ; now attend to the case when the terminalsare insulated. Having got the dielectric into the state representedby I., screw down the clamp and wait. If some ofthe beads slide, while some do not, we shall shortlyarrive at the state represented by II. Beads Nos.… … Fig. 7.—Stages in the discharge of a stratified condenser, with some of its layers ofimperfect insulating power ; showing one way in which the phenomena of residual charge, internal charge, and soaking out are produced.I. represents a recent charge, of E. M.F. 24.II, represents the same after lapse…
