Fig. 7—Three-Quarters-Floating Axle part of these thrusts, and as it is rigidly connected to thewheel by a flange, it must be strong enough to resist thoseside thrusts which tend to bend it. Full-Floating Axle The full-floating axle (Fig. 8) is formed by adding asecond bearing to both wheel hubs of… … Fig. 8—Full-Floating Axle far enough apart to take the side thrusts and leave theshafts free from bending stresses. It will be readily seenthat the shafts are really free from all stresses excepttwisting at both ends, and hence full-fioating. Final Drive The conventional two-wheel rear drive is…
