tensile resistance, all FLEXUKE OP KKINFOECED CONCRETE BEAMS. 347 tension being borne by the steel rods or re-inforcement. Fig.297 shows a side view and also an end-yiew of a portion of thebeam in Fig. 291 extending from the left-hand support up toany section DS (or up to TFin Fig. 291). As before,… … Fig. 297. tances from a neuti-al axis iV, at some distance e from the topfiber of the flange, where the unit compressive stress has somevalue p. Also, since the U for concrete in compression is to be takenas constant the stresses in the concrete will also be proportionalto the distances of the…
