requently succumbs—to forget to work ones way infrom the corner of the cube to the centre. That is tosay, an extra 5 feet on the line of height on the rightwUl not measure the height of the apex, because .thewall of height for the corner does not go through theapex. The dotted axis of cube and… … FiG. 182. -Diagram Q. 4 240 Perspective angular Hook also lying on the ground-plane, on which is apoint F. The horizon, centre of vision, distance of the eyefrom the picture, and the ground-line are given. Find thedimensions of the rectangle, and draw in perspective asimilar rectangle of the same…
