Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)

Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 120

An illustration from Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features, 1911, leaf 120
PLATE 106—WALL, WINDOW AND PORCH DETAILS Wall section shows use of rough boards laideight inches to the weather for the first story upto the second story window sills, with cement plaster above. Working details of casement win-dows, also double hung windows. Details ofporch cornice showing use of… … Q. € I I Z2s3zzszzsaszsn^zszs2sm^ DETAIL OF MAIN STAIR HALL

Building

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
